Workholding & ToolHolding

A rotary table is used to rotate a workpiece precisely during machining, allowing for accurate creation of circular features, angles, and indexing tasks. A chuck is used to securely hold and grip a workpiece on a machine tool, ensuring it remains stable and aligned during operations like turning, drilling, or milling. 3"/ 80 mm Rotary Table Small low profile Rotary Table for Milling operation with Table Diameter - 3 Inches (80 mm) Vertical Height - 1-5/8 Inch Gear Ratio - 36:1, which basically means that the 1 rotation of the handle shall rotate the table by 10 degrees. Base Dimensions: 4. 1/8" x 3. 1/4" 4 T-Slots: 5/16" Table scale is calibrated in 5 degree increement. Can be used both in horizontal & vertical position. Chuck 50mm 3 Jaw Self Centering Precision 50 mm 3-Jaw Self-Centering Lathe Chuck Compatible with M12 x 1 mm threading Chuck 50 mm 4 Jaw Self Centering Precision 50 mm 4-Jaw Self-Centering Lathe Chuck Compatible with M12 x 1 mm threading Chuck 50 mm 4 Jaw Independent Precision 50 mm 4-Jaw Independent Lathe Chuck Compatible with M12 x 1 mm threading Chuck 65 mm 3 Jaw Self Centering Precision 65mm 3-Jaw Self-Centering Lathe Chuck Compatible with M14 x 1 mm threading Chuck 65 mm 4 Jaw Self Centering Precision 65mm 4-Jaw Self-Centering Lathe Chuck Compatible with M14 x 1 mm threading Chuck 70 mm 4 Jaw Independent Precision 70 mm 4-Jaw Independent Lathe Chuck Compatible with M14 x 1 mm threading Chuck 80 mm 3 Jaw Self Centering Recess is 55 mm Total Height excluding the jaws (Only Body) : 45 mm. The Back plate is drilled with M6 size tapped holes for the chuck's bolts to be screwed with the back plate and then provided with 2 counter drills to them clamp it with the Rotary table's T slots. 80 mm 3 jaw self centering chuck with spare set of reversible jaws and a chuck key, Also included a suitable steel back plate with fixing t nuts and bolts to enable this to mount it on this. The Chuck body is made of high grain casting and the jaws are made of hardened tool steel for a long life. The chuck recess is 55 mm same as that of the back plate. The back plate has a 13.9 mm small spigot that helps it in centrally locate it in the center of the Rotary Table. Chuck 80 mm 4 Jaw Independent 80 mm 4 Jaw Independent Chuck with a Backplate & 3 Sets of T-Nuts The other side of the Back plate has a small spigot to fit /adjust into the center of the Rotary table for better accuracy and Fitting. Supplied with Fixing T nuts Bolts. Body is made of Graded Casting. Jaws are of Alloy Tool Steel -Hardened and Ground Supplied with a Tool Steel Back Plate having same recess as that of the chuck. The plate is threaded drilled in a manner that the chuck can be screwed to the Back Plate The Back plate has been counter drilled to fit to our 3"/ 80mm & 4"/ 100 mm Rotary tables.

Read more less

The chuck for a rotary table typically has jaws or clamps that can be adjusted to securely grip the workpiece. It ensures that the workpiece remains stable and properly aligned during the machining process, allowing for accurate and consistent results. This is especially important for tasks that require precise positioning or multiple machining operations on different sides of the workpiece. Enhance the precision and versatility of your rotary tables and mini lathes with our high-quality small chucks. Designed for 3" (80 mm) and 4" (100 mm) rotary tables, these chucks come with durable steel back plates, ensuring a secure and reliable fit for various machining tasks. Key Features: High-Quality Construction: Crafted from premium-grade steel, our chucks offer exceptional durability and longevity. The steel back plates ensure a robust connection to rotary tables and mini lathes. Precision Engineering: Engineered for high accuracy, these chucks provide excellent concentricity and grip. Ideal for precise machining operations requiring tight tolerances. Versatile Compatibility: Suitable for 3" (80 mm) and 4" (100 mm) rotary tables. Compatible with a wide range of mini lathes, making them a versatile addition to your workshop. Easy Installation: Designed for quick and straightforward installation, saving you valuable time and effort. Includes all necessary mounting hardware for hassle-free setup. Secure Grip: Features high clamping force to securely hold workpieces in place during machining. Reduces the risk of slippage and enhances safety. Technical Specifications: Chuck Sizes Available: 3" (80 mm) and 4" (100 mm) Material: Premium-Grade Steel Back Plate Material: Tool Steel Applications: Ideal for use in metalworking, woodworking, and hobbyist projects. Perfect for precision machining, turning, and drilling tasks on rotary tables and mini lathes. Package Includes: 1 x Small Chuck for 3" (80 mm) or 4" (100 mm) Rotary Table 1 x Steel Back Plate Mounting Hardware Why Choose Us: Customer-Centric Service: We are dedicated to providing exceptional customer support and ensuring your satisfaction. Expertise: With over a decade of experience in the machine tool accessories industry, we deliver products you can trust. Global Reach: Serving customers across the USA, India, and now expanding to the UK, we are committed to meeting your machining needs wherever you are. Order Yours Today: Upgrade your machining setup with our premium small chucks. Place your order now and experience the difference in quality and performance!

Read more less

The small watchmaker rotary table is a versatile tool with a multitude of uses. It's indispensable in precision watchmaking, enabling accurate drilling, milling, and engraving for crafting and repairing intricate watch components. Additionally, it's favored by jewelry makers for its ability to shape metals with precision, from setting stones to creating bespoke jewelry pieces. Small Watchmaker 2-3/4" (2.75 Inch) Rotary Table The small watchmaker rotary table is a versatile tool with a multitude of uses. It's indispensable in precision watchmaking, enabling accurate drilling, milling, and engraving for crafting and repairing intricate watch components. Additionally, it's favored by jewelry makers for its ability to shape metals with precision, from setting stones to creating bespoke jewelry pieces. Compact Design: Table Diameter of 2.75 inches (72 mm) and a height of 1.5 inches (39 mm) when laid horizontally, offering a space-efficient solution. Precision Performance: Worm-Gear Ratio of 1:48 ensures precise positioning, with each handle rotation turning the table by 7.5 degrees, ideal for intricate milling tasks. Versatile Utility: Preferred choice among Watchmakers, Jewelry Tools, Model Makers & Hobbyists for its versatility in engraving, drilling, cutting, and shaping small components. Robust Construction: Crafted with high-quality materials and precision machining, guaranteeing durability and reliability for professional workshops and hobbyist setups. Smooth Operation: Equipped with smooth ball bearings and precision gearing, enabling effortless rotation and stable operation for flawless milling results. User-Friendly: Designed with ergonomic handles and intuitive controls for ease of use, reducing operator fatigue during extended milling sessions. Trusted Performance: Trusted by professionals and hobbyists alike for consistent precision and reliability, meeting exacting standards for precision milling applications. Available in 2 slots and 4 slots 50 mm Chuck -3 Jaw Self Centering (M12 x 1) Caste Iron Body 50 mm 3 Jaws Self Chucks with Tool Steel Hardened Jaws Body Diameter 50 mm , Mounting thread M12 x 1 It can hold any long round bar up to 12 mm, which can pass through the chuck's bore. 50 mm Chuck -4 Jaw Self Centering (M12 x 1) Caste Iron Body 50 mm 3 Jaws Self Chucks with Tool Steel Hardened Jaws Body Diameter 50 mm , Mounting thread M12 x 1 It can hold any long round bar up to 12 mm, which can pass through the chuck's bore. 50 mm Chuck - 4 Independent (M12 x 1) Caste Iron Body 50 mm 4 jaw Independent Dog Chucks with Hardened Tool Steel Jaws Graded Caste Iron Body and Hardened Tool Steel Jaws Mounting thread M14 x 1, same as that of the Arbors. Jaws are Hardened & Precisely Ground. Great for Holding Small Jobs upto 12 mm diameter both for Metal or Wood Working

Read more less

A collet chuck block adapter is used to enable a CNC machine spindle to securely hold and accurately center tools of different sizes using interchangeable collets, thus enhancing machining versatility, efficiency, and precision. Features: High Precision ID Ground: The internal diameter is precisely ground to ensure exceptional accuracy and a tight fit for ER-32 collets. Blue Matched Finish: The collet chuck block features a durable blue finish, providing corrosion resistance and an aesthetically pleasing appearance. Versatile Compatibility: Compatible with ER-32 collets, making it suitable for a wide range of machining applications. Robust Construction: Made from high-quality alloy steel for superior strength and longevity. Ease of Use: Designed for quick and easy installation on CNC lathes, improving workflow efficiency. Enhanced Performance: Provides stable and reliable holding power, ensuring consistent machining results. Applications: CNC Lathe Operations Milling Machines Drilling and Tapping Precision Machining Tool and Die Making Specifications: Type: ER-32 Collet Chuck Block Adapter Material: Alloy Steel Finish: Blue Matched Internal Diameter: Precision Ground Compatibility: ER-32 Collets Comes in: Hex Shape, Square Shape Benefits: High Precision: Ensures accurate and consistent machining operations. Durable Finish: Blue matched finish offers protection against corrosion and wear. Versatility: Suitable for a wide range of CNC lathe and machining applications. Time-Saving: Quick and easy to install, reducing setup time and increasing productivity. Reliable Performance: Provides stable holding power for consistent machining results. Why Choose Our ER-32 Collet Chuck Block Adapter? Unmatched Precision: Our collet chuck block adapter is precision-engineered to meet the highest standards of accuracy, ensuring reliable performance in every use. Durability: Constructed from high-quality materials and finished with a blue matched coating, this adapter is built to withstand the rigors of heavy-duty machining. Versatile Use: Whether you’re working on a CNC lathe, milling machine, or other precision machining equipment, this adapter is designed to deliver exceptional results. Upgrade your CNC lathe operations with our Precision ID Ground Blue Matched ER-32 Collet Chuck Block Adapter and experience the difference in performance and precision.

Read more less

ER collet adapters are used to expand the range of tool sizes that can be held by a machine tool or spindle that uses ER collets. By using ER collet adapters, machinists can utilize a wider range of cutting tools without needing separate dedicated tool holders for each collet size, thereby optimizing tooling flexibility, reducing costs, and streamlining setup and changeover times in manufacturing processes. Introduction: ER collet adaptors are precision tool holders used to secure cutting tools in rotary milling tables. They provide a robust and versatile solution for various machining tasks, ensuring high accuracy and repeatability. Design and Construction: Made from high-quality, hardened steel for durability and long-lasting performance. Precision ground to ensure a perfect fit and maximum concentricity. Available in various sizes to accommodate different tool shanks. Compatibility: Designed to fit standard rotary milling tables. Compatible with a wide range of ER collet sizes (e.g., ER11, ER16, ER20) Suitable for use with CNC machines, lathes, and manual milling machines. Clamping Range: ER collets offer a wide clamping range, typically from 1mm to 34mm, depending on the collet size. Provides a secure grip on the tool, minimizing vibration and runout during machining. Advantages: High precision: Ensures accurate tool positioning and stable machining operations. Versatility: Can hold various types of tools, including end mills, drill bits, and taps. Ease of use: Simple to install and change tools quickly, reducing downtime. Improved productivity: Enhances machining efficiency by maintaining tool stability and reducing tool wear. By following these points, users can understand the key features and benefits of ER collet adaptors for rotary milling tables, ensuring they select the right adaptor for their specific machining needs.

Read more less

 How it's works: When mounted onto a rotary table, which is a precision workholding device that allows for precise positioning of workpieces, the dividing plate helps in accurately dividing the rotation of the table into equal parts. This division is crucial for tasks like cutting gears, splines, or other components that require precise angular spacing or indexing. Premium Quality Construction: Constructed from high-grade tool steel, ensuring durability and longevity for extended usage. Precision Indexing: Engineered for precise division and indexing, allowing for accurate positioning of workpieces during machining operations. Smooth Rotation: Facilitates smooth rotation on rotary tables, enabling seamless transitions between indexing positions. Versatile Compatibility: Compatible with a wide range of rotary tables, ensuring versatility and adaptability for various machining setups. Enhanced Machining Accuracy: Enables users to achieve fine increments and accurate divisions, enhancing overall machining precision. Easy Installation: Designed for hassle-free installation, allowing users to quickly integrate the indexing plates into their rotary table setups. Reliable Performance: Offers reliable performance under demanding machining conditions, ensuring consistent results with each use. Professional Grade: Ideal for both professional machinists and hobbyists alike, providing professional-grade quality for diverse machining projects. Tools Specification: Dividing Plates Set for HV4 /HV6 Rotary Table: Set Includes: 3 x Indexing Dividing Plate and accessories. Diameter of the Plates is 100 mm. Centre Hole of the Plate is 21 mm. Thickness 7 mm Plate 1 – 15, 16, 17, 18, 19, 20 Plate 2 – 21, 23, 27, 29, 31, 33 Plate 3 – 37, 39, 41, 43, 47, 49 Dividing Plates Set for HV8 /HV10/ HV12/ HV14 Rotary Table: Set Includes: 2 x Indexing Dividing Plate and accessories. Diameter of the plate is 7" and its thickness is 0.47 " Inches (12 mm) approx. All required accessories are included as photograph. No manual is included, please note. Plate A - 28, 32, 37, 39, 43, 46, 49, 53, 59 Plate B - 63, 69, 73, 79, 83, 89, 93, 99 {Internal reference: HM}

Read more less

Purpose: The chuck for a rotary table typically has jaws or clamps that can be adjusted to securely grip the workpiece. It ensures that the workpiece remains stable and properly aligned during the machining process, allowing for accurate and consistent results. This is especially important for tasks that require precise positioning or multiple machining operations on different sides of the workpiece. Versatile Chuck Set: Upgrade your rotary table or mini lathe with this set of small chucks designed to fit  HV4 I 5 I 6 Rotary Tables and Lathe machines, enhancing their functionality and versatility. Precision Engineering: Crafted with precision to ensure optimal performance, these chucks provide secure grip and smooth rotation, essential for accurate machining and turning operations. Durable Construction: Made from high-quality caste iron, these chucks are built to withstand the rigors of machining tasks, ensuring long-lasting durability and reliability. Easy Installation: Simple to install and compatible with most rotary tables and mini lathes, these chucks allow for quick setup and seamless integration into your workshop or machining setup. Wide Application: Ideal for a variety of machining projects, these chucks enable you to securely hold workpieces of different shapes and sizes, expanding the capabilities of your rotary table or mini lathe. Compact Design: With their small size, these chucks are perfect for use with compact machinery, allowing you to maximize space efficiency in your workshop without sacrificing performance. Enhanced Efficiency: By providing a secure and stable grip on workpieces, these chucks help improve machining accuracy and efficiency, allowing you to achieve professional results with ease. Professional Results: Whether you're a hobbyist or a professional machinist, these small chucks are essential tools for achieving precision and accuracy in your machining and turning projects. {Internal Refence: HM}

Read more less

Purpose: The chuck for a rotary table typically has jaws or clamps that can be adjusted to securely grip the workpiece. It ensures that the workpiece remains stable and properly aligned during the machining process, allowing for accurate and consistent results. This is especially important for tasks that require precise positioning or multiple machining operations on different sides of the workpiece. Versatile Chuck Set: Upgrade your rotary table or mini lathe with this set of small chucks designed to fit 3" (80 mm) and 4" (100 mm) machines, enhancing their functionality and versatility. Precision Engineering: Crafted with precision to ensure optimal performance, these chucks provide secure grip and smooth rotation, essential for accurate machining and turning operations. Durable Construction: Made from high-quality materials, these chucks are built to withstand the rigors of machining tasks, ensuring long-lasting durability and reliability. Easy Installation: Simple to install and compatible with most rotary tables and mini lathes, these chucks allow for quick setup and seamless integration into your workshop or machining setup. Wide Application: Ideal for a variety of machining projects, these chucks enable you to securely hold workpieces of different shapes and sizes, expanding the capabilities of your rotary table or mini lathe. Compact Design: With their small size, these chucks are perfect for use with compact machinery, allowing you to maximize space efficiency in your workshop without sacrificing performance. Enhanced Efficiency: By providing a secure and stable grip on workpieces, these chucks help improve machining accuracy and efficiency, allowing you to achieve professional results with ease. Professional Results: Whether you're a hobbyist or a professional machinist, these small chucks are essential tools for achieving precision and accuracy in your machining and turning projects. ( 80 mm 4 Jaws Independent Dog chuck with Back Plate )  The Back plate has been counter drilled to fit to our 3"/ 80mm & 4"/ 100 mm Rotary tables. The other side of the Back plate has a small spigot to fit /adjust into the center of the Rotary table for better accuracy and Fitting. Supplied with Fixing T nuts Bolts.  ( 80 mm 3 Jaws Self Centering chuck )  3" /80 mm Rotary table. Recess is 55 mm Total Height excluding the jaws (Only Body) : 45 mm. The Back plate is drilled with M6 size tapped holes for the chuck's bolts to be screwed with the back plate and then provided with 2 counter drills to them clamp it with the Rotary table's T slots. The Chuck body is made of high grain casting and the jaws are made of hardened tool steel for a long life. The chuck recess is 55 mm same as that of the back plate. The back plate has a 13.9 mm small spigot that helps it in centrally locate it in the center of the Rotary Table. {Internal Refence: HM}

Read more less

Use of product- Back plates serve as mounting surfaces for workpieces or fixtures. They facilitate the secure attachment of the workpiece or fixture to the rotary table, enabling precise machining operations such as milling, drilling, or grinding. Additionally, back plates may incorporate features such as T-slots or mounting holes to accommodate different types of workpieces and tooling setups, enhancing versatility and accuracy in machining processes. Enhance the versatility and functionality of your rotary table with our precision back plate. Crafted from high-quality [Material], this back plate ensures reliable performance and durability for all your machining needs. Features: Robust Construction: Engineered from sturdy tool steel, our back plate is built to withstand heavy-duty machining operations, providing stable support for your workpieces. Precision Machining: Designed with meticulous attention to detail, our back plate offers precise alignment and compatibility with your rotary table, ensuring accurate machining results. Universal Compatibility: Compatible with a wide range of rotary tables, our back plate is a versatile addition to your workshop, catering to various machining projects. Easy Installation: Installing our back plate is quick and straightforward, allowing you to attach it to your rotary table effortlessly for immediate use. Secure Mounting: Equipped with sturdy mounting holes, our back plate ensures a secure and stable connection to your rotary table, minimizing vibrations during machining. Smooth Surface Finish: Finished with a smooth surface, our back plate provides an ideal mounting surface for your workpieces, reducing friction and enhancing machining precision. Size Options: 65 mm diameter back plate in M12 x 1 and M14 x 1 thread. Package Includes: 1 x Precision Back Plate for Rotary Table 3 x Tee Nuts Bolts Upgrade your machining capabilities with our precision back plate for rotary tables. Order now and experience enhanced accuracy and efficiency in your workshop!

Read more less

Back plates serve as mounting surfaces for workpieces or fixtures. They facilitate the secure attachment of the workpiece or fixture to the rotary table, enabling precise machining operations such as milling, drilling, or grinding. Additionally, back plates may incorporate features such as T-slots or mounting holes to accommodate different types of workpieces and tooling setups, enhancing versatility and accuracy in machining processes. Enhance the versatility and functionality of your rotary table with our precision back plate. Crafted from high-quality [Material], this back plate ensures reliable performance and durability for all your machining needs. Features: Robust Construction: Engineered from sturdy tool steel, our back plate is built to withstand heavy-duty machining operations, providing stable support for your workpieces. Precision Machining: Designed with meticulous attention to detail, our back plate offers precise alignment and compatibility with your rotary table, ensuring accurate machining results. Universal Compatibility: Compatible with a wide range of rotary tables, our back plate is a versatile addition to your workshop, catering to various machining projects. Easy Installation: Installing our back plate is quick and straightforward, allowing you to attach it to your rotary table effortlessly for immediate use. Secure Mounting: Equipped with sturdy mounting holes, our back plate ensures a secure and stable connection to your rotary table, minimizing vibrations during machining. Smooth Surface Finish: Finished with a smooth surface, our back plate provides an ideal mounting surface for your workpieces, reducing friction and enhancing machining precision. Size Options: 70 mm diameter back plate in M12 x 1 and M14 x 1 thread. Package Includes: [1] x Precision Back Plate for Rotary Table [3] x Tee Nuts Bolts Upgrade your machining capabilities with our precision back plate for rotary tables. Order now and experience enhanced accuracy and efficiency in your workshop! {Internal Reference: HM}

Read more less

A Soft Machinable Blank Arbor is a cylindrical tool or component used in machining processes, particularly in the manufacturing and tooling industry. It serves as a blank canvas for creating custom arbors tailored to specific machining needs Soft blank arbors are used in machining for creating custom tooling, fixtures, and precise components with tailored configurations, enabling versatile and accurate machining operations.. Here's a detailed description: Material: Typically made from soft machinable materials alloy tool Steel. These materials are chosen for their ease of machining and shaping. Shape: The arbor is cylindrical in shape, with precise dimensions to fit into machining equipment such as lathes, milling machines, or drill presses. It may have various diameters and lengths depending on the intended application. Customization: Unlike pre-made arbors, the soft machinable blank arbor allows for customization according to specific requirements. Machinists can shape, drill, tap, and modify the blank arbor to create unique configurations suited to different machining tasks. Versatility: Soft machinable blank arbors offer versatility in their usage. They can be used for holding and securing workpieces, tooling, or other accessories during machining operations. Applications: Soft machinable blank arbors find applications in various industries such as automotive, aerospace, manufacturing, and prototyping. They are used in tasks ranging from simple drilling and milling operations to complex machining projects requiring custom fixtures and tooling. Overall, the soft machinable blank arbor is a versatile and customizable tool essential for machinists and manufacturers seeking precision and flexibility in their machining processes.

Read more less

Use of product- A rotary table is a precision tool used predominantly in metalworking, particularly in machining operations like milling and drilling. Its primary function lies in enabling machining at precise angular intervals around a fixed point, commonly referred to as indexing. This capability facilitates the creation of intricate geometries, circular features, and multi-sided machining without the need for manual repositioning of the workpiece. By mounting the workpiece on the rotary table and rotating it, machinists can execute complex operations such as gear cutting, spiral grooving, and helical cuts with high precision. Additionally, rotary tables are essential for tasks requiring circular or arc-shaped machining, offering versatility and efficiency in manufacturing processes. Precision Engineering: Crafted with meticulous attention to detail, our HV4-MT2 Center Bore Rotary Table ensures superior accuracy and performance in your machining operations. Table Diameter is 110 mm & Regular table when Horizontally laid Height: 80 mm (3 -1/8" ). For tilting Table:- base diameter : 175 x 45 mm , Tee slot width : 11 mm Height ( horizontal) : 120mm, center height in vertical position : 80mm center bore : 2MT Robust Construction: Built with quality materials, this rotary table boasts a sturdy and durable design, providing long-lasting reliability in your workshop. Worm Gear Ratio - 1:90, which means that 1 handle rotation shall turn the table by 4 Degrees MT2 Center Bore: Features a reliable MT2 center bore, offering secure mounting and precise alignment for your workpieces. Center Bore of the Table MT2 Table Graduated 360 Degrees. Handwheel graduated in seconds. Versatile Compatibility: Compatible with a wide range of machining tasks, including milling, drilling, cutting threads, and more, making it a versatile addition to your workshop. Ample Space: With its HV4 size, this rotary table provides ample space for accommodating various workpieces, allowing you to tackle a variety of projects with ease. Easy to Use: Designed for user convenience, this rotary table is easy to set up and operate, ensuring a smooth and efficient workflow in your machining tasks. Professional Grade: Whether you're a professional machinist or a hobbyist, our HV4-MT2 Center Bore Rotary Table offers professional-grade performance and reliability for all your machining needs. Essential Tool: A must-have tool for any workshop, this rotary table enhances your machining capabilities and helps you achieve precision and accuracy in your projects. Satisfaction Guaranteed: Backed by our commitment to quality and customer satisfaction, our HV4-MT2 Center Bore Rotary Table comes with a satisfaction guarantee, ensuring your peace of mind with every purchase. Upgrade Your Workshop: Elevate your workshop with the superior performance and versatility of our HV4-MT2 Center Bore Rotary Table, the perfect addition to any machining setup. {Internal Reference; HM}

Read more less
