Description
A rotary table is a precision work positioning device used in metalworking. It enables the operator to drill or cut work at exact intervals around a fixed (usually horizontal or vertical) axis.
A clamp kit for a rotary table is used to secure workpieces onto the rotary table during machining operations. Rotary tables are often used in machining setups to enable circular cutting, hole drilling, and other operations around a fixed axis of rotation.
Key Features:
-
Compact & Low-Profile Design:
-
Table Diameter: The rotary table features a 3-inch (80 mm) diameter, making it perfect for small-scale milling operations where space and precision are critical.
-
Vertical Height: With a vertical height of just 1-5/8 inches, this rotary table maintains a low profile, enabling it to fit seamlessly into your existing setup while maximizing available workspace.
-
Precision Engineering:
-
Gear Ratio: The rotary table boasts a 36:1 gear ratio, ensuring precise control over the rotation. One full rotation of the handle results in a 10-degree rotation of the table, allowing for meticulous adjustments during milling tasks.
-
Scale Calibration: The table scale is finely calibrated in 5-degree increments, providing clear and accurate angle measurements. This feature is particularly useful for tasks requiring high precision and consistency.
-
Versatile Positioning:
-
Horizontal & Vertical Use: This rotary table is designed for maximum versatility, capable of operating in both horizontal and vertical positions. This dual functionality allows for a wide range of applications, from simple flat milling to more complex angular cuts.
-
Robust Construction:
-
Base Dimensions: The base of the rotary table measures 4-1/8" x 3-1/4", providing a stable and secure platform for your work. The compact dimensions ensure that the table remains sturdy during use, minimizing vibrations and enhancing accuracy.
-
T-Slots: The base is equipped with four 5/16" T-slots, allowing for secure clamping of workpieces. These slots are designed to accommodate various clamping setups, ensuring your workpiece remains firmly in place throughout the milling process.
M6 Clamp Kit
- This M6 clamp kit is designed for use with 3" or 4" rotary tables.
- Includes a set of clamps, bolts, nuts, and T-slot nuts.
- Compatible with rotary tables featuring M6 T-slots or mounting holes.
- Allows for secure fastening of workpieces onto the rotary table during machining operations.
- Made of tool steel for durability and reliability.
- Provides essential holding power to maintain precision and accuracy.
- Ideal for use in machining setups requiring precise rotary table positioning.
