Description
The primary purpose of a V jig fixture is to provide support and guidance for the workpiece, minimizing movement or vibration that could lead to errors in machining. By securely holding the workpiece in place, it allows operators to perform machining operations with greater precision and efficiency.
-
Material:
- Constructed from high-grade caste iron for enhanced durability and strength.
- Precision-machined surfaces to ensure long-lasting performance and accuracy.
-
Capacity:
- Designed to accommodate round workpieces up to 2 inches in diameter.
- Suitable for a wide range of cylindrical materials including metal, wood, and plastic.
-
Design:
- V-groove at a 90-degree angle to securely hold round workpieces in place.
- Integrated jig fixture for precise center drilling operations.
- Compact and portable design for easy handling and storage.
- Measures 5" Long X 4" Wide.
-
Clamping Mechanism:
- Features robust clamps to hold the workpiece firmly during drilling.
- Adjustable clamps to fit varying diameters within the 2" capacity.
-
Base:
- Stable, flat base to minimize movement and vibration during use.
- Anti-slip pads on the base for additional stability and safety.
-
Finish:
- Smooth, corrosion-resistant finish to prevent rust and wear.
- Coated for added protection and longevity.
Applications:
Benefits:
-
High Precision:
- Guarantees precise and repeatable center drilling operations.
- Reduces setup time and increases productivity.
-
Durability:
- Made from graded caste iron for long-term use.
- Resistant to wear and tear even under heavy-duty conditions.
-
Versatility:
- Suitable for a variety of materials and machining applications like drilling, milling, grinding.
- Compatible with various machine tools and setups.
Maintenance:
- Clean the V-block jig fixture regularly to remove debris and metal shavings.
- Apply a light coat of oil to prevent rust and maintain smooth operation.
- Store in a dry, cool place when not in use.
Warranty:
- Comes with a 1-month manufacturer warranty.
- Dedicated customer support for any inquiries or assistance.
