Description
A rotary table is a precision tool used predominantly in metalworking, particularly in machining operations like milling and drilling. Its primary function lies in enabling machining at precise angular intervals around a fixed point, commonly referred to as indexing. This capability facilitates the creation of intricate geometries, circular features, and multi-sided machining without the need for manual repositioning of the workpiece.
A clamp kit for a rotary table is used to secure workpieces onto the rotary table during machining operations. Rotary tables are often used in machining setups to enable circular cutting, hole drilling, and other operations around a fixed axis of rotation.
-
Table Diameter: 4 inches (100 mm)
This size is ideal for handling small to medium-sized workpieces, offering a good balance between compactness and functionality.
-
360-Degree Graduation:
The table is graduated a full 360 degrees, allowing for precise control and positioning of the workpiece. The clear markings ensure easy and accurate angle setting for all your milling tasks.
-
Worm Gear Ratio: 1:36
The gear ratio means that one full rotation of the handle turns the table by 10 degrees, providing fine control over the movement and ensuring precision in every operation.
-
Vertical Position Center Height: 2-1/16" (50 mm approx)
The center height in the vertical position is 2-1/16 inches, which aligns perfectly with the smaller milling machine setups, offering versatility in workpiece positioning.
-
Handwheel Graduations:
The handwheel is graduated in divisions of 10 minutes, allowing for highly detailed adjustments. The scale can also be set to zero, making it easy to track and repeat your adjustments for consistent results.
-
Mounting Flexibility:
The Regular model can be mounted in both horizontal and vertical positions, enhancing its versatility for a wide range of applications. Whether you need flat or angled cuts, this rotary table can handle it with ease.
M6 Clamp Kit
- This M6 clamp kit is designed for use with 3" or 4" rotary tables.
- Includes a set of clamps, bolts, nuts, and T-slot nuts.
- Compatible with rotary tables featuring M6 T-slots or mounting holes.
- Allows for secure fastening of workpieces onto the rotary table during machining operations.
- Made of tool steel for durability and reliability.
- Provides essential holding power to maintain precision and accuracy.
- Ideal for use in machining setups requiring precise rotary table positioning.
